Image preview - the first page of the document
![Panel_ZHIXUAN_ZXXS410-L01_0_[DS]](/pics/5eb08b9cedb15.gif)
>> Download Panel_ZHIXUAN_ZXXS410-L01_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
XXS410-L01 Product Specification
Rev.01
Model Name: XXS410-L01
Issue Date : 2013/06/21
( )Preliminary Specifications
( )Final Specifications
Customer Signature Date TYLOO SPECIAL DISPLAY TECH Date
Approved By Approval By PM Director
_________________________________ ____________________________________
Note Reviewed By RD Director
____________________________________
Reviewed By Project Leader
____________________________________
Prepared By PM
____________________________________
HIXUAN Display Technology Co. 2013 All Rights Reserved. 1 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
XXS410-L01 Product Specification
Rev.01
Contents
No
CONTENTS
RECORD OF REVISIONS
1 GENERAL DESCRIPTION
2 ABSOLUTE MAXIMUM RATINGS
3 ELECTRICAL SPECIFICATION
3-1 ELECTRIACL CHARACTERISTICS
3-2 INTERFACE CONNECTIONS
3-3 SIGNAL TIMING SPECIFICATION
3-4 SIGNAL TIMING WAVEFORM
3-5 COLOR INPUT DATA REFERENCE
3-6 POWER SEQUENCE
3-7 BACKLIGHT SPECIFICATION
4 OPTICAL SPECIFICATION
5 MECHANICAL CHARACTERISTICS
6 RELIABILITY TEST ITEMS
7 INTERNATIONAL STANDARD
7-1 SAFETY
7-2 EMC
8 PACKING
8-1 DEFINITION OF LABEL
8-2 PACKING METHODS
8-3 PALLET AND SHIPMENT INFORMATION
9 PRECAUTION
9-1 MOUNTING PRECAUTIONS
9-2 OPERATING PRECAUTIONS
9-3 ELECTROSTATIC DISCHARGE CONTROL
9-4 PRECAUTIONS FOR STRONG LIGHT EXPOSURE
9-5 STORAGE
9-6 HANDLING PRECAUTIONS FOR PROTECT FILM
HIXUAN Display Technology Co. 2013 All Rights Reserved. 2 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
XXS410-L01 Product Specification
Rev.01
Record of Revision
Version Date Page Description
0.1 2013/06/21 First release
HIXUAN Display Technology Co. 2013 All Rights Reserved. 3 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
XXS410-L01 Product Specification
Rev.01
1. General Description
This specification applies to the 41.0 inch Color TFT - LCD Module VT41CH01 . This LCD module has a TFT
active matrix type liquid crystal panel 1,920 x 232 pixels, and diagonal size of 41.0 inch. This modue supports
1,920 x 232 mode. Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical
stripes. Gray scale or the brightness of the sub-pixel color is determined with a 10-bit gray scale signal for each dot.
The VTC41CH01 has been designed to apply the 10-bit 2 channel LVDS interface method. It is intended to
support displays where high brightness, wide viewing angle, high color saturation, and high color depth are very
important.
* General Information
Items Specification Unit Note
Active Screen Size 41.00 inch
Display Area 1066(H) x 166(V)mm
1028.9(H) x 1303(V) mm
Outline Dimension 1056.9(H) x 159.5(V) x 27.1(D) mm D : Front bezel to rib
Driver Element a-Si TFT active matrix
Display Colors 10 bit, 16.7M Colors
Number of Pixels 1,920x232 Pixel
Pixel Pitch 0.53025(H) x 0.53025(W) mm
Pixel Arrangement RGB vertical stripe
Display Operation Mode Normally Black
Surface Treatment HC, 3H
HIXUAN Display Technology Co. 2013 All Rights Reserved. 4 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
XXS410-L01 Product Specification
Rev.01
2. Absolute Maximum Ratings
The followings are maximum values which, if exceeded, may cause faulty operation or damage to the unit
Item Symbol Min Max Unit Conditions
Logic/LCD Drive Voltage Vcc -0.3 14 [Volt] Note 1
Input Voltage of Signal Vin -0.3 4 [Volt] Note 1
o
Operating Temperature TOP 0 +40 [ C] Note 2
Operating Humidity HOP 20 80 [%RH] Note 2
o
Storage Temperature TST -10 +50 [ C] Note 2
Storage Humidity HST 20 80 [%RH] Note 2
o
Panel Surface Temperature PST 55 [ C] Note 3
Note 1: Duration:50 msec.
Note 2 : Maximum Wet-Bulb should be 39 and No condensation.
The relative humidity must not exceed 80% non-conde nsing at temperatures of 40 or less. At temperatures
greater than 40 , the wet bulb temperature must not exceed 39 .
Note 3: Surface temperature is measured at 50 Dry condition
Note 4: Storage period should refer to RA criteria
HIXUAN Display Technology Co. 2013 All Rights Reserved. 5 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
XXS410-L01 Product Specification
Rev.01
3. Electrical Specification
The VT41CH01 requires two power inputs. One is employed to power the LCD electronics and to drive the TFT
array and liquid crystal. The other is to power Back Light Unit.
3.1 Electrical Characteristics
3.1.1: DC Characteristics
Value
Parameter Symbol Unit Note
Min. Typ. Max
LCD
Power Supply Input Voltage VDD 10.8 12 13.2 VDC
Power Supply Input Current IDD -- 0.85 1.2 A 1
Power Consumption PC -- 10.2 67 WATT
Inrush Current IRUSH -- -- 4 A 2
Permissible Ripple of Power Supply Input Voltage VRP -- -- VDD * 5% mVpk-pk 3
Input Differential Voltage VID 200 400 600 mVDC 4
LVDS Differential Input High Threshold Voltage VTH +100 -- +300 mVDC 4
Interface
Differential Input Low Threshold Voltage VTL -300 -- -100 mVDC 4
Input Common Mode Voltage VICM 1.1 1.25 1.4 VDC 4
VIH
CMOS Input High Threshold Voltage 2.7 -- 3.3 VDC 5
(High)
Interface VIL
Input Low Threshold Voltage 0 -- 0.6 VDC 5
(Low)
Backlight Power Consumption PBL 55.8 57.6 59.4 Watt
Life time (MTTF) 50000 Hour 9,10
HIXUAN Display Technology Co. 2013 All Rights Reserved. 6 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
HIXUAN Product Specification
Rev.01
3.1.2: AC Characteristics
Value
Parameter Symbol Unit Note
Min. Typ. Max
Input Channel Pair Skew Margin tSKEW (CP) -500 -- +500 ps 6
Receiver Clock : Spread Spectrum Fclk Fclk
Fclk_ss -- MHz 7
Modulation range -3% +3%
LVDS
Interface Receiver Clock : Spread Spectrum
Fss 30 -- 200 KHz 7
Modulation frequency
Receiver Data Input Margin
Fclk = 85 MHz tRMG -0.4 -- 0.4 ns 8
Fclk = 65 MHz -0.5 -- 0.5
Note :
1. VDD = 12.0V, Fv = 60Hz, Fclk= 82MHz , 25 , Test Pattern : White Pattern
2. Measurement condition : Rising time = 400us
9''
*1'
s
3. Test Condition:
(1) The measure point of VRP is in LCM side after connecting the System Board and LCM.
(2) Under Max. Input current spec. condition.
4. VICM = 1.25V
LVDS -
V IC M V TH
|V ID |
V TL
LVDS +
GND
|V ID |
0V
|V ID |
HIXUAN Display Technology Co. 2013 All Rights Reserved. 7 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
XXS410-L01 Product Specification
Rev.01
5. The measure points of VIH and VIL are in LCM side after connecting the System Board and LCM.
6. Input Channel Pair Skew Margin
Note: x = 0, 1, 2, 3, 4
7. LVDS Receiver Clock SSCG (Spread spectrum clock generator) is defined as below figures
)6FF
6ONBV
6ONBV PD[ L
6ONB
6ONBV
6ONBV PDQ5L
DQ5L
HIXUAN Display Technology Co. 2013 All Rights Reserved. 8 / 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
XXS410-L01 Product Specification
Rev.01
8. Receiver Data Input Margin
Rating
Parameter Symbol Unit Note
Min Type Max
Input Clock Frequency Fclk Fclk (min) -- Fclk (max) MHz T=1/Fclk
Input Data Position0 tRIP1 -|tRMG| 0 |tRMG| ns
Input Data Position1 tRIP0 T/7-|tRMG| T/7 T/7+|tRMG| ns
Input Data Position2 tRIP6 2T/7-|tRMG| 2T/7 2T/7+|tRMG| ns
Input Data Position3 tRIP5 3T/7-|tRMG| 3T/7 3T/7+|tRMG| ns
Input Data Position4 tRIP4 4T/7-|tRMG| 4T/7 4T/7+|tRMG| ns
Input Data Position5 tRIP3 5T/7-|tRMG| 5T/7 5T/7+|tRMG| ns
Input Data Position6 tRIP2 6T/7-|tRMG| 6T/7 6T/7+|tRMG| ns
, 3GW
, 3G
, 3G
, 3G
, 3G
, 3G
, 3G
9'FS
W W
35X&, '[,[
9'FS
35X&, RN%OB 9IQ 7 9
)6ONB7/
9. The relative humidity must not exceed 80% non-condensing at temperatures of 40 or less. At
temperatures greater than 40 , the wet bulb temperature must not exceed 39 . When operate at low
temperatures, the brightness of LED will drop and the life time of LED will be reduced.
10. The lifetime (MTTF) is defined as the time which luminance of LED is 50% compared to its original value.
[Operating condition: Continuous operating at Ta = 25◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
