Image preview - the first page of the document
>> Download LG MZ-60PZ13 Plasma TV Service Manual documenatation <<
Text preview - extract from the document
REPLACEMENT PARTS LIST
LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION
IC8602 0IIR121130A 1R2113S 16SOP R/TP H/BRIDGE DR
IC
IC8603 0IRH103392A BA10339FV-E2 SSOP-B14PIN R/TP
IC102 0IDS232000A DS232AS 16P,SOP TP RS-232 DRIV
IC8604 0ISH121100D PQ12DZ1U 5 SMD R/TP REGULATOR
IC103 0ISH052100C PQ05RD21 4SIP ST REGULATOR
IC8631 0IUN386300B UC3863DW 20PLCC R/TP PFZO CONT
IC104 0IMO741230E SN74LS123D 14P,SOP TP MONO MUL
IC8801 0ISK666813A STR-F6668B(LF1352) 5PIN BK STR
IC201 0IIT323000C VPC3230D-QA-B3 80P PQFP BK COM
IC8802 0ISK005000A SE005N 3P TO-220 BK 5V ERROR A
IC202 0IKE704200J KIA7042AF SOT-89 TP 4.2V VOLTA
IC8803 0IFA754207A KA75420ZTA(KA7542ZTA) 3P,TO-92
IC203 0ISO210100B CXA2101AQ 80P,QFP BK VIDEO SIG
IC8804 0ISK805011A SI-8050S(LF1113) 5PIN BK 5V RE
IC204 0ISH092100A PQ09RF21 4P 9V S/W REGULATOR -
IC8806 0ISK812011A SI-8120S(LF1113) 5PIN BK 12V R
IC205 0ISH052100C PQ05RD21 4SIP ST REGULATOR
IC8900 0ISH817300B PC817XF3 4D PHOTO COUPLER
IC402 0ISS464323A K4S643232E(C)-TC/L70(KM432S203
PC8201 0ILI817000G LTV817M-VB 4P,DIP BK PHOTO COU
IC403 0IMCRG2001A FLI2200 SAGE 176P,QFP TRAY VID
PC8202 0ILI817000G LTV817M-VB 4P,DIP BK PHOTO COU
IC404 0IMCRG2002A FLI2220 SAGE 160P,QFP TRAY DIG
PC8401 0ILI817000G LTV817M-VB 4P,DIP BK PHOTO COU
IC406 0IMCRAD001A ADV7123KSTC140 ANALOG DEVICE 4
PC8402 0ILI817000G LTV817M-VB 4P,DIP BK PHOTO COU
IC501 0IMCRG2004A JAGASM SAGE 352BALL TRAY HIGHL
PC8403 0ILI817000G LTV817M-VB 4P,DIP BK PHOTO COU
IC502 0ISS464323A K4S643232E(C)-TC/L70(KM432S203
PC8501 0ILI817000G LTV817M-VB 4P,DIP BK PHOTO COU
IC503 0ISS464323A K4S643232E(C)-TC/L70(KM432S203
PC8502 0ISH851000A PC851 4P,DIP BK HIGH VOLTAGE P
IC601 0IIT344000B MSP3440G QA A4 QA 80QFP TP AUD
PC8503 0ILI817000G LTV817M-VB 4P,DIP BK PHOTO COU
IC602 0IKE704200J KIA7042AF SOT-89 TP 4.2V VOLTA
PC8504 0ILI817000G LTV817M-VB 4P,DIP BK PHOTO COU
IC603 0ISA428200A LA4282 12S 2CHX10W AUDIO AMP
PC8801 0ILI817000G LTV817M-VB 4P,DIP BK PHOTO COU
IC604 0ISH052100C PQ05RD21 4SIP ST REGULATOR
PC8802 0ILI817000G LTV817M-VB 4P,DIP BK PHOTO COU
IC605 0IKE780800A KIA7808PI 3P(TO-220IS) 1A,8V -
IC701 0IMI623200B M62320FP,I/O EXPANDER 16P SOP TRANSISTOR
IC702 0IMI623200B M62320FP,I/O EXPANDER 16P SOP
Q001 0TR103009AD KRC103M(AT) TO-92M TP KEC
IC703 0IMI623200B M62320FP,I/O EXPANDER 16P SOP
Q002 0TR103009AD KRC103M(AT) TO-92M TP KEC
IC704 0IAL241610A AT24C16N-10SI 8P SOIC ST EEPRO
Q101 0TR387500AA CHIP 2SC3875S(ALY) KEC
IC706 0IMCRNS001A LM810 NATIONAL SEMICONDUCTOR 3
Q102 0TR387500AA CHIP 2SC3875S(ALY) KEC
IC707 0IPH740400G 74HC04D HEX INVERTER 14P,SOP T
Q103 0TR387500AA CHIP 2SC3875S(ALY) KEC
IC708 0IPH806520A 80C652 40 PLCC ST 8-BIT MICROC
Q104 0TR387500AA CHIP 2SC3875S(ALY) KEC
IC709 0IZZVA0035B AT27C020 32-PIN DIP ST NTSC .
Q105 0TR387500AA CHIP 2SC3875S(ALY) KEC
IC710 0IPH743730E 74HCT373D 20SOP R/TP ADDRESS L
Q106 0TR387500AA CHIP 2SC3875S(ALY) KEC
IC801 0IUN385400B UC3854BDW 20PLCC R/TP PFC CONT
Q107 0TR387500AA CHIP 2SC3875S(ALY) KEC
IC802 0IMCRRH001A BA033FP ROHM 3P-SOP,TO252-3 R/
Q108 0TR387500AA CHIP 2SC3875S(ALY) KEC
IC803 0ILT176425A LT1764EQ-2.5 5PIN Q PACKAGE R
Q109 0TR387500AA CHIP 2SC3875S(ALY) KEC
IC804 0IMCRRH001A BA033FP ROHM 3P-SOP,TO252-3 R/
Q110 0TR387500AA CHIP 2SC3875S(ALY) KEC
IC806 0IMCRRH001A BA033FP ROHM 3P-SOP,TO252-3 R/
Q111 0TR387500AA CHIP 2SC3875S(ALY) KEC
IC807 0ILT176425A LT1764EQ-2.5 5PIN Q PACKAGE R
Q112 0TR387500AA CHIP 2SC3875S(ALY) KEC
IC808 0IPH743200A 74HC32D 14SOP TP QUAD 2-INPUT
Q113 0TR387500AA CHIP 2SC3875S(ALY) KEC
IC901 0IS5150000A SII150 100QFP BK PANEL LINK TR
Q114 0TR387500AA CHIP 2SC3875S(ALY) KEC
IC1101 0IMCRAT003A EPM7064STC44-100 ALTERA 44P,QF
Q115 0TR387500AA CHIP 2SC3875S(ALY) KEC
IC1102 0ISH052100C PQ05RD21 4SIP ST REGULATOR
Q116 0TR387500AA CHIP 2SC3875S(ALY) KEC
IC8102 0IIR121130A 1R2113S 16SOP R/TP H/BRIDGE DR
Q121 0TR104009AF CHIP KRC104S SOT-23 TP KEC - -
IC8103 0IRH103392A BA10339FV-E2 SSOP-B14PIN R/TP
Q250 0TR150400BA CHIP 2SA1504S(ASY) KEC
IC8104 0ISH121100D PQ12DZ1U 5 SMD R/TP REGULATOR
Q251 0TR150400BA CHIP 2SA1504S(ASY) KEC
IC8131 0IUN386300B UC3863DW 20PLCC R/TP PFZO CONT
Q252 0TR150400BA CHIP 2SA1504S(ASY) KEC
IC8201 0IPF255000A TNY255P 8DIP ST LOW POWER OFF-
Q301 0TR387500AA CHIP 2SC3875S(ALY) KEC
IC8202 0IPF255000A TNY255P 8DIP ST LOW POWER OFF-
Q302 0TR387500AA CHIP 2SC3875S(ALY) KEC
IC8204 0ITI431000D TL431ILP LP003 VAR.ZENER
Q303 0TR150400BA CHIP 2SA1504S(ASY) KEC
IC8205 0IKE781200P KIA7812API TO220 ST 3P 12V REG
Q304 0TR387500AA CHIP 2SC3875S(ALY) KEC
- 18 -
LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION
Q404 0TR150400BA CHIP 2SA1504S(ASY) KEC Q8905 0TR102009AG CHIP KRC102S SOT-23 TP KEC
Q405 0TR150400BA CHIP 2SA1504S(ASY) KEC Q8906 0TR102009AG CHIP KRC102S SOT-23 TP KEC
Q406 0TR150400BA CHIP 2SA1504S(ASY) KEC Q8907 0TR387500AA CHIP 2SC3875S(ALY) KEC
Q601 0TR150400BA CHIP 2SA1504S(ASY) KEC Q8908 0TR150400BA CHIP 2SA1504S(ASY) KEC
Q602 0TR150400BA CHIP 2SA1504S(ASY) KEC Q8909 0TR102009AG CHIP KRC102S SOT-23 TP KEC
Q603 0TR150400BA CHIP 2SA1504S(ASY) KEC
DIODE
Q801 0TR387500AA CHIP 2SC3875S(ALY) KEC
Q802 0TR176608AA 2SD1766Q R/TP ROHM KOREA SMD F D101 0DD226239AA CHIP KDS226 SOT-23
Q803 0TR387500AA CHIP 2SC3875S(ALY) KEC D102 0DD226239AA CHIP KDS226 SOT-23
Q804 0TR118008AA 2SB1188Q R/TP ROHM KOREA SMD F D103 0DD226239AA CHIP KDS226 SOT-23
Q806 0TR387500AA CHIP 2SC3875S(ALY) KEC D104 0DD226239AA CHIP KDS226 SOT-23
Q808 0TR387500AA CHIP 2SC3875S(ALY) KEC D105 0DD226239AA CHIP KDS226 SOT-23
Q7105 0TR387500AA CHIP 2SC3875S(ALY) KEC D106 0DD226239AA CHIP KDS226 SOT-23
Q7107 0TR387500AA CHIP 2SC3875S(ALY) KEC D250 0DD226239AA CHIP KDS226 SOT-23
Q8101 0TR150400BA CHIP 2SA1504S(ASY) KEC D251 0DD226239AA CHIP KDS226 SOT-23
Q8102 0TR150400BA CHIP 2SA1504S(ASY) KEC D252 0DD184009AA KDS184S CHIP 85V 300MA KEC TP
Q8104 0TR150400BA CHIP 2SA1504S(ASY) KEC D401 0DL233309AC LED,SAM2333 TP KWANG GREEN/RED
Q8105 0TR387500AA CHIP 2SC3875S(ALY) KEC D402 0DL233309AC LED,SAM2333 TP KWANG GREEN/RED
Q8106 0TR102009AG CHIP KRC102S SOT-23 TP KEC D601 0DD184009AA KDS184S CHIP 85V 300MA KEC TP
Q8107 0TR150400BA CHIP 2SA1504S(ASY) KEC D602 0DD184009AA KDS184S CHIP 85V 300MA KEC TP
Q8108 0TR387500AA CHIP 2SC3875S(ALY) KEC D603 0DD184009AA KDS184S CHIP 85V 300MA KEC TP
Q8201 0TR319809AA KTC3198 TP KEC - - -Y (KTC1815 D604 0DD226239AA CHIP KDS226 SOT-23
Q8203 0TR102009AB KRC102M,TP(KRC1202),KEC D610 0DD226239AA CHIP KDS226 SOT-23
Q8204 0TR319809AA KTC3198 TP KEC - - -Y (KTC1815 D801 0DZ240009CG ZENERS,MTZJ24B
Q8205 0TR102009AB KRC102M,TP(KRC1202),KEC D802 0DD100009AM EU1ZV(1) TP SANKEN
Q8206 0TR319809AA KTC3198 TP KEC - - -Y (KTC1815 D802 0DZ910009AJ ZENERS,MTZJ9.1B
Q8207 0TR322709AA KTC3227-Y,TP(KTC1627A),KEC D803 0DZ750009AG ZENERS,MTZJ7.5B
Q8208 0TR322709AA KTC3227-Y,TP(KTC1627A),KEC D804 0DZ240009CG ZENERS,MTZJ24B
Q8210 0TR319809AA KTC3198 TP KEC - - -Y (KTC1815 D805 0DD120000BB FML-G12S
Q8303 0TFIR10001A INTERNATIONAL RECTIFIER IRFPS3 D807 0DZRM00178A ZENERS,UDZS TE-17 5.1B ROHM
Q8304 0TFIR10001A INTERNATIONAL RECTIFIER IRFPS3 D1101 0DD226239AA CHIP KDS226 SOT-23
Q8401 0TF283700AA 2SK2837 BK TOSHIBA 500V 20A TO D8101 0DZ620009BB ZENERS,MTZJ6.2B
Q8402 0TF283700AA 2SK2837 BK TOSHIBA 500V 20A TO D8102 0DR011009AA EG01AV1 TP SANKEN NON 600V 0.5
Q8403 0TR322709AA KTC3227-Y,TP(KTC1627A),KEC D8104 0DD184009AA KDS184S CHIP 85V 300MA KEC TP
Q8502 0TF283700AA 2SK2837 BK TOSHIBA 500V 20A TO D8105 0DD184009AA KDS184S CHIP 85V 300MA KEC TP
Q8503 0TF283700AA 2SK2837 BK TOSHIBA 500V 20A TO D8202 0DD414809ED 1N4148 TA
Q8505 0TR320709AA KTC3207,TP(KTC2482),KEC D8203 0DD260000BB BRIDGE D2SBA60(STK) SHINDENKEN
Q8601 0TR150400BA CHIP 2SA1504S(ASY) KEC D8204 0DD110009DB RM11CV(1) TP SANKEN TP SANKEN
Q8602 0TR150400BA CHIP 2SA1504S(ASY) KEC D8205 0DD100009AP EG1ZV(1) TP SANKEN TP SANKEN
Q8604 0TR150400BA CHIP 2SA1504S(ASY) KEC D8206 0DD120000BB FML-G12S
Q8605 0TR387500AA CHIP 2SC3875S(ALY) KEC D8208 0DD100009DK RU1P V(1) TP SANKEN
Q8606 0TR102009AG CHIP KRC102S SOT-23 TP KEC D8210 0DZ160009BC ZENERS,MTZJ16B
Q8607 0TR150400BA CHIP 2SA1504S(ASY) KEC D8211 0DZ180009AG ZENERS,MTZJ18B
Q8608 0TR387500AA CHIP 2SC3875S(ALY) KEC D8212 0DD100009DK RU1P V(1) TP SANKEN
Q8801 0TR385200AA 2SC3852A SANKEN D8213 0DD100009AP EG1ZV(1) TP SANKEN TP SANKEN
Q8802 0TR319809AA KTC3198 TP KEC - - -Y (KTC1815 D8214 0DZ680009BB ZENERS,MTZJ6.8B
Q8803 0TR319809AA KTC3198 TP KEC - - -Y (KTC1815 D8215 0DZ300009BB ZENERS,MTZJ30B
Q8900 0TR387500AA CHIP 2SC3875S(ALY) KEC D8216 0DZ300009BB ZENERS,MTZJ30B
Q8901 0TR387500AA CHIP 2SC3875S(ALY) KEC D8217 0DZ750009AG ZENERS,MTZJ7.5B
Q8902 0TR387500AA CHIP 2SC3875S(ALY) KEC D8301 0DD414809ED 1N4148 TA
Q8903 0TR387500AA CHIP 2SC3875S(ALY) KEC D8302 0DD414809ED 1N4148 TA
Q8904 0TR387500AA CHIP 2SC3875S(ALY) KEC D8303 0DB250600AB RBV-2506 BK SANKEN - 600V 25A
- 19 -
For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film
the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film
digit in the P/No. means as CE : Electrolytic RN : Metal Film
follows; RF : Fusible
LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION
D8304 0DR310000BA RM3A LF-U1 BK SANKEN - 600V 2. D8820 0DD100009AM EU1ZV(1) TP SANKEN
D8305 0DR310000BA RM3A LF-U1 BK SANKEN - 600V 2. D8821 0DZ120009AF ZENERS,MTZJ12B
D8306 0DD410009AA SCHOTTKY,BAT 41 TP D8822 0DZ750009AG ZENERS,MTZJ7.5B
D8307 0DD410009AA SCHOTTKY,BAT 41 TP D8900 0DD184009AA KDS184S CHIP 85V 300MA KEC TP
D8311 0DR360000BA FMB-36M BK SANKEN - 0.62V - - D8901 0DD184009AA KDS184S CHIP 85V 300MA KEC TP
D8312 0DD100009AP EG1ZV(1) TP SANKEN TP SANKEN D8903 0DD226239AA CHIP KDS226 SOT-23
D8313 0DZ680009BB ZENERS,MTZJ6.8B D8904 0DD226239AA CHIP KDS226 SOT-23
D8315 0DZ620009BD ZENER,P6KE200A TP G.I NON 5W 200V 1M D8907 0DD226239AA CHIP KDS226 SOT-23
D8316 0DZ620009BD ZENER,P6KE200A TP G.I NON 5W 200V 1M LD001 0DL200000CA LED,SAM5670(DL-2LRG) BK Y-GREEN
D8319 0DD410009AA SCHOTTKY,BAT 41 TP LD801 0DL233309AC LED,SAM2333 TP KWANG GREEN/RED
D8401 0DD100009AP EG1ZV(1) TP SANKEN TP SANKEN LD802 0DL233309AC LED,SAM2333 TP KWANG GREEN/RED
D8402 0DD414809ED 1N4148 TA LD803 0DL233309AC LED,SAM2333 TP KWANG GREEN/RED
D8403 0DD414809ED 1N4148 TA ZD103 0DR050008AA SD05.TC R/TP SEMTECH SOD323 5V
D8404 0DR240000BA FML-24S BK SANKEN TO220 400V 1 ZD104 0DR050008AA SD05.TC R/TP SEMTECH SOD323 5V
D8405 0DZ330009BA ZENER,HZT33(TP) HITACHI ZD105 0DR050008AA SD05.TC R/TP SEMTECH SOD323 5V
D8406 0DZ330009BA ZENER,HZT33(TP) HITACHI ZD8902 0DZRM00178A ZENERS,UDZS TE-17 5.1B ROHM R/TP SMD
D8407 0DD100009AP EG1ZV(1) TP SANKEN TP SANKEN ZD8906 0DZ750009AG ZENERS,MTZJ7.5B TP ROHM-K DO34 0.5W 7
D8408 0DZ120009AF ZENERS,MTZJ12B ZD8908 0DZRM00178A ZENERS,UDZS TE-17 5.1B ROHM R/TP SMD
D8409 0DZ680009BB ZENERS,MTZJ6.8B
D8411 0DZ360009BC ZENERS,MTZJ3.6B
CAPACITOR
D8412 0DZ330009BA ZENER,HZT33(TP) HITACHI C001 0CN1040K949 0.1M 50V Z
D8414 0DR220000CA FMM-22S BK SANKEN TO220 200V 1 C002 0CE476DD618 47UF STD 10V 20%
D8418 0DD414809ED 1N4148 TA C109 0CE476SF6DC 47UF MVG 16V M
D8419 0DZ120009AF ZENERS,MTZJ12B C112 0CE476SF6DC 47UF MVG 16V M
D8501 0DD100009AP EG1ZV(1) TP SANKEN TP SANKEN C115 0CE476SF6DC 47UF MVG 16V M
D8502 0DZ610009AA ZENER,P6KE100A TP G.I NON 1W 100V 1M C118 0CE476SF6DC 47UF MVG 16V M
D8503 0DZ610009AA ZENER,P6KE100A TP G.I NON 1W 100V 1M C125 0CE106SF6DC 10UF MVG 16V 20%
D8504 0DD100009AP EG1ZV(1) TP SANKEN TP SANKEN C128 0CE476SF6DC 47UF MVG 16V M
D8505 0DR240000BA FML-24S BK SANKEN TO220 400V 1 C129 0CE476SF6DC 47UF MVG 16V M
D8506 0DD100009AP EG1ZV(1) TP SANKEN TP SANKEN C130 0CE476SF6DC 47UF MVG 16V M
D8507 0DD100009AP EG1ZV(1) TP SANKEN TP SANKEN C135 0CE476SF6DC 47UF MVG 16V M
D8508 0DZ120009AF ZENERS,MTZJ12B C136 0CE476SF6DC 47UF MVG 16V M
D8509 0DR240000BA FML-24S BK SANKEN TO220 400V 1 C139 0CE476SF6DC 47UF MVG 16V M
D8510 0DZ680009BB ZENERS,MTZJ6.8B C166 0CE476SF6DC 47UF MVG 16V M
D8511 0DZ610009AA ZENER,P6KE100A C168 0CE107SF6DC 100UF MVG 16V M
D8515 0DD414809ED 1N4148 TA C171 0CE107SF6DC 100UF MVG 16V M
D8601 0DZ620009BB ZENERS,MTZJ6.2B C173 0CE107SF6DC 100UF MVG 16V M
D8602 0DR011009AA EG01AV1 TP SANKEN NON 600V 0.5 C202 0CE106SF6DC 10UF MVG 16V 20%
D8604 0DD184009AA KDS184S CHIP 85V 300MA KEC TP C203 0CE107SF6DC 100UF MVG 16V M
D8605 0DD184009AA KDS184S CHIP 85V 300MA KEC TP C205 0CK224DF56A 220000PF 2012 16V 10%
D8801 0DD100009AM EU1ZV(1) TP SANKEN C212 0CK224DF56A 220000PF 2012 16V 10%
D8802 0DD100009AM EU1ZV(1) TP SANKEN C214 0CE106SF6DC 10UF MVG 16V 20%
D8803 0DD414809ED 1N4148 TA C224 0CE476SF6DC 47UF MVG 16V M
D8804 0DD100009DK RU1P V(1) TP SANKEN C227 0CE476SF6DC 47UF MVG 16V M
D8811 0DR290000AA FMB-29L BK SANKEN TO220 90V 8A C230 0CK224DF56A 220000PF 2012 16V 10%
D8812 0DR360000CA FML-36S BK SANKEN TO3P 600V 20 C233 0CE476SF6DC 47UF MVG 16V M
D8813 0DR360000CA FML-36S BK SANKEN TO3P 600V 20 C246 0CE106SF6DC 10UF MVG 16V 20%
D8814 0DZ910009AJ ZENERS,MTZJ9.1B C255 0CE476SF6DC 47UF MVG 16V M
D8815 0DD414809ED 1N4148 TA C267 0CE105SK6DC 1UF MVG 50V M
D8816 0DR460009AA RK46 TP SANKEN DO-214AC 60V 3. C274 0CE107SF6DC 100UF MVG 16V M
D8818 0DR460009AA RK46 TP SANKEN DO-214AC 60V 3. C275 0CE107SF6DC 100UF MVG 16V M
D8819 0DZ150009AD ZENERS,MTZJ15B C278 0CE476SF6DC 47UF MVG 16V M
- 20 -
For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film
the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film
digit in the P/No. means as CE : Electrolytic RN : Metal Film
follows; RF : Fusible
LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION
C288 0CE106SF6DC 10UF MVG 16V 20% C655 0CE107DH618 100UF STD 25V M
C290 0CE106SF6DC 10UF MVG 16V 20% C655 0CE477DK618 470UF STD 50V 20%
C293 0CE476SF6DC 47UF MVG 16V M C656 0CE107DH618 100UF STD 25V M
C297 0CE107SF6DC 100UF MVG 16V M C656 0CE477DK618 470UF STD 50V 20%
C300 0CE107SF6DC 100UF MVG 16V M C658 0CQ6821N509 0.0068U 100V K
C310 0CE476SF6DC 47UF MVG 16V M C659 0CE106SF6DC 10UF MVG 16V 20%
C373 0CE1051K636 1UF SM,SA 50V 20% C659 181-120K 2200PF 4KV M
C402 0CE476SF6DC 47UF MVG 16V M C660 0CQ6821N509 0.0068U 100V K
C405 0CE476SF6DC 47UF MVG 16V M C660 181-120K 2200PF 4KV M
C408 0CE476SF6DC 47UF MVG 16V M C661 0CQ1041N509 0.1U 100V K
C411 0CE476SF6DC 47UF MVG 16V M C662 0CQ1041N509 0.1U 100V K
C414 0CE476SF6DC 47UF MVG 16V M C699 0CE227VF6DC 220UF MV 16V 20%
C439 0CE476SF6DC 47UF MVG 16V M C709 0CE476SF6DC 47UF MVG 16V M
C441 0CE476SF6DC 47UF MVG 16V M C711 0CE106SF6DC 10UF MVG 16V 20%
C442 0CE476SF6DC 47UF MVG 16V M C715 0CE106SF6DC 10UF MVG 16V 20%
C471 0CE106SF6DC 10UF MVG 16V 20% C717 0CE106SF6DC 10UF MVG 16V 20%
C476 0CE106SF6DC 10UF MVG 16V 20% C718 0CE106SF6DC 10UF MVG 16V 20%
C479 0CE476SF6DC 47UF MVG 16V M C720 0CE105SK6DC 1UF MVG 50V M
C487 0CE106SF6DC 10UF MVG 16V 20% C801 0CE106WH6DC 10UF MVK 25V 20%
C503 0CE106SF6DC 10UF MVG 16V 20% C802 0CE227VF6DC 220UF MV 16V 20%
C506 0CE106SF6DC 10UF MVG 16V 20% C804 0CE105WK6DC 1UF MVK 50V 20%
C509 0CE106SF6DC 10UF MVG 16V 20% C806 0CE227VF6DC 220UF MV 16V 20%
C512 0CE106SF6DC 10UF MVG 16V 20% C809 0CE105WK6DC 1UF MVK 50V 20%
C515 0CE106SF6DC 10UF MVG 16V 20% C810 0CE227VF6DC 220UF MV 16V 20%
C518 0CE106SF6DC 10UF MVG 16V 20% C811 0CE106WH6DC 10UF MVK 25V 20%
C521 0CE106SF6DC 10UF MVG 16V 20% C813 0CE106WH6DC 10UF MVK 25V 20%
C524 0CE106SF6DC 10UF MVG 16V 20% C814 0CE476SF6DC 47UF MVG 16V M
C554 0CE106SF6DC 10UF MVG 16V 20% C815 0CE476SF6DC 47UF MVG 16V M
C601 0CE476SF6DC 47UF MVG 16V M C818 0CE106WH6DC 10UF MVK 25V 20%
C602 0CE476SF6DC 47UF MVG 16V M C818 0CE227VF6DC 220UF MV 16V 20%
C604 0CE106SF6DC 10UF MVG 16V 20% C820 0CE105WK6DC 1UF MVK 50V 20%
C609 0CE107SF6DC 100UF MVG 16V M C821 0CE107SF6DC 100UF MVG 16V M
C610 0CE106SF6DC 10UF MVG 16V 20% C824 0CE227VF6DC 220UF MV 16V 20%
C611 0CE106SF6DC 10UF MVG 16V 20% C825 0CE106SF6DC 10UF MVG 16V 20%
C612 0CE335SK6DC 3.3UF MVG 50V 20% C826 0CE476SF6DC 47UF MVG 16V M
C614 0CE106SF6DC 10UF MVG 16V 20% C828 0CE106SF6DC 10UF MVG 16V 20%
C616 0CE106SF6DC 10UF MVG 16V 20% C829 0CE106SF6DC 10UF MVG 16V 20%
C626 0CE107SF6DC 100UF MVG 16V M C832 0CE476SF6DC 47UF MVG 16V M
C627 0CE107SF6DC 100UF MVG 16V M C834 0CE106SF6DC 10UF MVG 16V 20%
C630 0CE477DK618 470UF STD 50V 20% C843 0CE227VF6DC 220UF MV 16V 20%
C631 0CE477DK618 470UF STD 50V 20% C844 0CE227VF6DC 220UF MV 16V 20%
C640 0CE474SK6DC 0.47UF MVG 50V M C847 0CE227VF6DC 220UF MV 16V 20%
C641 0CE474SK6DC 0.47UF MVG 50V M C849 0CE476SF6DC 47UF MVG 16V M
C643 0CE474SK6DC 0.47UF MVG 50V M C850 0CE476SF6DC 47UF MVG 16V M
C644 0CE474SK6DC 0.47UF MVG 50V M C855 0CE476SF6DC 47UF MVG 16V M
C647 0CE107SF6DC 100UF MVG 16V M C856 0CE476SF6DC 47UF MVG 16V M
C651 0CE227VF6DC 220UF MV 16V 20% C861 0CE106SF6DC 10UF MVG 16V 20%
C652 0CE105SK6DC 1UF MVG 50V M C863 0CE477BF618 470UF KME 16V M
C653 0CE107DH618 100UF STD 25V M C864 0CE477BF618 470UF KME 16V M
C653 0CE477DK618 470UF STD 50V 20% C869 0CE108DF618 1000UF STD 16V M
C654 0CE106SF6DC 10UF MVG 16V 20% C870 0CE477BF618 470UF KME 16V M
C654 0CE477DK618 470UF STD 50V 20% C871 0CE107SF6DC 100UF MVG 16V M
- 21 -
For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film
the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film
digit in the P/No. means as CE : Electrolytic RN : Metal Film
follows; RF : Fusible
LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION
C874 0CE227VF6DC 220UF MV 16V 20% C8322 0CQZVBK002B A.C 275V 0.15UF K (S=22.5)
C876 0CE106SF6DC 10UF MVG 16V 20% C8327 181-033E 1KV B 222K
C877 0CE106SF6DC 10UF MVG 16V 20% C8328 181-033E 1KV B 222K
C1103 0CE106SF6DC 10UF MVG 16V 20% C8329 181-033E 1KV B 222K
C1106 0CE107SF6DC 100UF MVG 16V M C8330 181-033E 1KV B 222K
C1110 0CE107SF6DC 100UF MVG 16V M C8331 181-091G DEHR33D471KN3A 470PF 2KV 10%,-
C1113 0CE476SF6DC 47UF MVG 16V M C8332 181-120K 2200PF 4KV M
C1720 0CE106SF6DC 10UF MVG 16V 20% C8333 181-120K 2200PF 4KV M
C7116 0CE475WJ6DC 4.7UF MVK 35V 20% C8336 0CB8241Y474 0.82UF D 630V J
C8101 0CE106WH6DC 10UF MVK 25V 20% C8401 181-091R R 1000PF 1KV 10%,-10%
C8105 0CE106WH6DC 10UF MVK 25V 20% C8402 0CC47001505 47PF 1KV K SL TR
C8106 0CE106WH6DC 10UF MVK 25V 20% C8404 0CC47001505 47PF 1KV K SL TR
C8110 0CE106WH6DC 10UF MVK 25V 20% C8407 0CBZVBK001B 0.056UF 800V J
C8202 0CQ1031N509 0.01U 100V K C8409 0CC47001505 47PF 1KV K
C8203 0CE105BK618 1UF KME 50V M C8410 0CQ2231N509 0.022U 100V K
C8204 0CE226BV611 22UF KME TYPE 450V M C8411 0CE337RV6A0 330UF KMH 450V M
C8205 0CE477BJ618 470UF KME TYPE 35V 20% C8412 0CE227BP650 220UF KME TYPE 160V 20%
C8207 0CE226BV611 22UF KME TYPE 450V M C8413 0CE227BP650 220UF KME TYPE 160V 20%
C8208 0CK1040K945 0.1UF 50V Z C8414 0CE227BP650 220UF KME TYPE 160V 20%
C8210 0CE477BH618 470UF KME TYPE 25V 20% C8416 0CQ1041N509 0.1U 100V K
C8211 0CK1040K945 0.1UF 50V Z C8504 181-091R R 1000PF 1KV 10%,-10%
C8212 0CE108BF618 1000UF KME 16V M C8506 0CBZVBK001B 0.056UF 800V J
C8213 181-091P SL 270PF 1KV 10%,-10% C8507 181-033T 2KV B 222K
C8214 181-091P SL 270PF 1KV 10%,-10% C8508 0CBZVBK001B 0.056UF 800V J
C8215 181-033E 1KV B 222K C8510 0CC47001505 47PF 1KV K
C8216 0CE108BF618 1000UF KME 16V M C8511 0CE687RP6A0 680UF KMH 160V M
C8217 181-091P SL 270PF 1KV 10%,-10% C8512 0CC47001505 47PF 1KV K SL TR
C8218 0CE105EV618 1UF KMG 450V M C8513 0CC47001505 47PF 1KV K SL TR
C8219 0CE105EV618 1UF KMG 450V M C8514 0CC47001505 47PF 1KV K SL TR
C8221 181-013U MPP 630V 0.1UF J C8515 0CC47001505 47PF 1KV K SL TR
C8222 0CE227BH618 220UF KME 25V M C8517 0CE687RP6A0 680UF KMH 160V M
C8225 0CK1040K945 0.1UF 50V Z C8518 0CE827RR6A0 820UF KMH 250V M
C8301 0CQZVBK002D A.C 275V 0.47UF K (S=22.5) C8519 0CE827RR6A0 820UF KMH 250V M
C8302 0CQZVBK002D A.C 275V 0.47UF K (S=22.5) C8520 0CE827RR6A0 820UF KMH 250V M
C8303 0CQZVBK002D A.C 275V 0.47UF K (S=22.5) C8521 0CQ1031N509 0.01U 100V K
C8304 181-120K 2200PF 4KV M C8522 181-007H MPE ECQ-V1H474JL3(TR), 50V 0.4
C8305 181-120K 2200PF 4KV M C8523 181-120K 2200PF 4KV M
C8306 0CQZVBK002D A.C 275V 0.47UF K (S=22.5) C8524 0CE476BK618 47UF KME 50V M
C8307 0CB8241Y474 0.82UF D 630V J C8525 0CQ4731N509 0.047U 100V K
C8308 0CB8241Y474 0.82UF D 630V J C8601 0CE106WH6DC 10UF MVK 25V 20%
C8309 181-035N DE1010 B KD 471M C8605 0CE106WH6DC 10UF MVK 25V 20%
C8311 0CE337RV6A0 330UF KMH 450V M C8606 0CE106WH6DC 10UF MVK 25V 20%
C8312 0CE337RV6A0 330UF KMH 450V M C8610 0CE106WH6DC 10UF MVK 25V 20%
C8313 181-035N DE1010 B KD 471M C8802 0CE227BK618 220UF KME 50V M
C8314 0CE337RV6A0 330UF KMH 450V M C8803 0CK8210K515 820P 50V K
C8315 181-091D DEHR33A102KN2A 1000PF 1KV 10%, C8804 181-011B 0.001UF D 1.6KV J
C8316 181-033E 1KV B 222K C8805 0CK8210K515 820P 50V K
C8317 181-091D DEHR33A102KN2A 1000PF 1KV 10%, C8807 181-010P PP 630V 0.068UF J
C8318 181-091G DEHR33D471KN3A 470PF 2KV 10%,- C8808 181-033T 2KV B 222K
C8319 181-091G DEHR33D471KN3A 470PF 2KV 10%,- C8811 181-007T MPE ECQ-V1H105JL3(TR), 50V 1.0
C8320 0CE477BH618 470UF KME TYPE 25V 20% C8812 0CE478BH650 4700UF KME 25V M
C8321 0CQZVBK002D A.C 275V 0.47UF K (S=22.5) C8813 0CE478BH650 4700UF KME 25V M
- 22 -
For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film
the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film
digit in the P/No. means as CE : Electrolytic RN : Metal Film
follows; RF : Fusible
LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION
C8815 0CE478BH650 4700UF KME 25V M T8801 151-A10H TRANSFORMER,SMPS[COIL] EER4445(H) 550UH
C8817 0CE478BH650 4700UF KME 25V M
CONNECTOR
C8818 0CE475BK618 4.7UF KME TYPE 50V 20%
C8819 0CE228EJ61A 2200UF KMG 35V M P001B 387-B04H CONNECTOR ASSY,4P (L=450)
C8820 0CQ1041N509 0.1U 100V K P003A 387-A10L CONNECTOR ASSY,10P (L=700)
C8821 0CQ1041N509 0.1U 100V K P101 6630VGA001C CONNECTOR,D-SUB 15PIN 2.29MM
C8822 0CE108BJ618 1000UF KME 35V M P102 6630GL00181 CONNECTOR,D-SUB 36P 2.
C8824 0CE108BK61A 1000UF KME 50V M P804A 387-A05A CONNECTOR ASSY,5P (L=100)
C8825 0CE108BK61A 1000UF KME 50V M P805A 387-A07A CONNECTOR ASSY,7P (L=100)
C8834 0CE228BF618 2200UF KME 16V M P806A 387-A05F CONNECTOR ASSY,5P (L=350)
C8835 0CE228BF618 2200UF KME 16V M P807A 387-A15A CONNECTOR ASSY,12P(L=100)
C8836 0CE228BF618 2200UF KME 16V M P808A 387-A04A CONNECTOR ASSY,4P (L=100)
C8839 0CE228BF618 2200UF KME 16V M P1001 6630VGA004B CONNECTOR,D-SUB 9P 2.77MM
C8841 0CQ1041N509 0.1U 100V K P8301A 6932V25002D CONNECTOR,HOUSING 2.5MM 6P
C8900 0CE107BH618 100UF KME 25V M P8302A 6932V25002D CONNECTOR,HOUSING 2.5MM 6P
C8901 0CE226BK618 22UF KME 50V M
C8903 0CE106DK618 10UF STD 50V M
RESISTOR
C8905 0CE107BH618 100UF KME 25V M AR201 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
C8907 0CE336DH618 33UF STD 25V 20% AR202 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
AR203 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
FUSE & JACK AR204 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
F8301 0FS1502B67B FUSE,SLOW BLOW 15000MA 250V AR401 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
L8811 131-096E FUSE,FAST BLOE 4000MA 125V AR402 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
JAC201 6612VLH002A JACK,RCA SP026B 4P RD/BK/BK/R AR403 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
P101 6612VJH018A JACK,RCA PJ6058C-A A/V 2P MON AR404 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
P102 380-389N JACK RCA S-456S-N AR405 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
P103 6612JH002BA RACK,RCA 456T-01 AR406 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
P201B 380-363J JACK,DIN PJ6046F AR407 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
AR408 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
COIL & TRANSFORMER
AR409 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
L001 0LA0102K119 INDUCTOR,10UH K AR410 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
L801 6140VB0004B COIL,CHOKE 26UH 1UEWPHY 22.5TURN AR411 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
L804 6140VB0004B COIL,CHOKE 26UH 1UEWPHY 22.5TURN AR412 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
L808 6140VB0004B COIL,CHOKE 26UH 1UEWPHY 22.5TURN AR413 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
L813 6140VB0004B COIL,CHOKE 26UH 1UEWPHY 22.5TURN AR414 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
L816 150-C02F COIL,CHOKE 82UH R1217 AR415 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
L8307 150-C02F COIL,CHOKE 82UH R1217 AR416 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
L8810 150-C04J COIL,CHOKE 3.8UH 0.65PHY 8.5TURN AR417 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
L8812 150-C04J COIL,CHOKE 3.8UH 0.65PHY 8.5TURN AR418 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
L8814 150-C02F COIL,CHOKE 82UH R1217 AR419 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
L8815 150-C02F COIL,CHOKE 82UH R1217 AR420 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
L8816 6170VZ0005B TRANSFORMER,H-DRIVER IRON-15 150UH AR421 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
L8819 6170VZ0005B TRANSFORMER,H-DRIVER IRON-15 150UH AR422 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
L8820 150-C02F COIL,CHOKE 82UH R1217 AR423 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
T8201 6170VS0001C TRANSFORMER,STAND-BY EE1927 1400UH AR424 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
T8202 151-D05D TRANSFORMER,STAND-BY EE1927 1200UH AR425 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
T8301 6170VG0001A TRANSFORMER,POWER CH400125 700UH 2*1.0 AR426 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
T8302 6170VG0001A TRANSFORMER,POWER CH400125 700UH 2*1.0 AR427 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
T8401 6170VMCA21C TRANSFORMER,SMPS[COIL] EER4244 250UH AR428 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
T8501 151-A10J TRANSFORMER,SMPS[COIL] EER4445(H) 360UH UC38 AR501 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
T8502 151-A10J TRANSFORMER,SMPS[COIL] EER4445(H) 360UH UC38 AR502 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
T8503 6170VMCA37A TRANSFORMER,SMPS[COIL] PQ3535 40UH UC3863DW AR503 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100
- 23 -
For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film
the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film
digit in the P/No. means as CE : Electrolytic RN : Metal Film
follows; RF : Fusible
LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION
AR504 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8202 0RD2203F609 220K OHM 1/6 W 5.00%
AR505 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8203 180-A04D RW RECT G 5W 10.0 J
AR506 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8204 0RS2002H609 20K OHM 1/2 W 5.00%
AR507 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8205 0RD1001F609 1K OHM 1/6 W 5.00%
AR508 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8206 0RD2202F609 22K OHM 1/6 W 5.00%
AR509 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8207 0RD2202F609 22K OHM 1/6 W 5.00%
AR510 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8208 0RD1002F609 10K OHM 1/6 W 5.00%
AR511 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8209 0RD1002F609 10K OHM 1/6 W 5.00%
AR512 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8210 0RD1002F609 10K OHM 1/6 W 5.00%
AR513 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8211 0RD1002F609 10K OHM 1/6 W 5.00%
AR514 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8212 0RD1002F609 10K OHM 1/6 W 5.00%
AR515 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8214 0RD1001F609 1K OHM 1/6 W 5.00%
AR516 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8216 0RD4702F609 47K OHM 1/6 W 5.00%
AR517 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8218 0RS0102H609 10 OHM 1/2 W 5.00%
AR518 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8220 0RD4702F609 47K OHM 1/6 W 5.00%
AR519 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8221 0RD4702F609 47K OHM 1/6 W 5.00%
AR520 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8225 0RS1000H609 100 OHM 1/2 W 5.00%
AR521 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8227 0RN3001F409 3K OHM 1/6 W 1.00%
AR522 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8228 0RN3901F409 3.9K OHM 1/6 W 1.00%
AR523 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8230 0RD1000F609 100 OHM 1/6 W 5.00%
AR524 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8231 0RD0331F609 3.3 OHM 1/6 W 5.00%
AR525 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8232 0RKZVTA001K 0.47M OHM 1/2 W 5%
AR526 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8233 0RD4701F609 4.7K OHM 1/6 W 5.00%
AR527 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8234 0RN8201F409 8.2K OHM 1/6 W 1.00%
AR528 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8235 0RKZVTA001K 0.47M OHM 1/2 W 5%
AR529 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8238 0RD4701F609 4.7K OHM 1/6 W 5.00%
AR530 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8301 0RMZVBK004C 4.7 OHM 10W +/-5% RWS V-TYPE
AR531 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8302 0RMZVBK004C 4.7 OHM 10W +/-5% RWS V-TYPE
AR532 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8303 0RMZVBK004C 4.7 OHM 10W +/-5% RWS V-TYPE
AR533 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8307 0RS0272H609 27 OHM 1/2 W 5.00%
AR534 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8308 0RS0272H609 27 OHM 1/2 W 5.00%
AR535 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8312 0RS0222H609 22 OHM 1/2 W 5.00%
AR701 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8313 0RS0222H609 22 OHM 1/2 W 5.00%
AR702 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8316 0RD1002F609 10K OHM 1/6 W 5.00%
AR703 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8318 0RD1002F609 10K OHM 1/6 W 5.00%
AR704 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8319 0RS0102H609 10 OHM 1/2 W 5.00%
AR705 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8320 0RS0102H609 10 OHM 1/2 W 5.00%
AR706 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 R8324 0RS5602K607 56K OHM 2 W 5.00%
D8309 0RS0222H609 22 OHM 1/2 W 5.00% R8325 0RS5602K607 56K OHM 2 W 5.00%
D8310 0RS0222H609 22 OHM 1/2 W 5.00% R8326 0RMZVBK001F 0.1 OHM 10W +/-5% MPR V-TYPE
R006 0RD3300F609 330 OHM 1/6 W 5.00% R8327 0RMZVBK001F 0.1 OHM 10W +/-5% MPR V-TYPE
R007 0RD3300F609 330 OHM 1/6 W 5.00% R8329 0RMZVBK001F 0.1 OHM 10W +/-5% MPR V-TYPE
R101 0RD0822F609 82 OHM 1/6 W 5.00% R8330 0RMZVBK001F 0.1 OHM 10W +/-5% MPR V-TYPE
R102 0RD0822F609 82 OHM 1/6 W 5.00% R8340 0RS4701H609 4.7K OHM 1/2 W 5.00%
R623 0RS0221H609 2.2 OHM 1/2 W 5.00% R8401 0RS0472H609 47 OHM 1/2 W 5.00%
R624 0RS0221H609 2.2 OHM 1/2 W 5.00% R8402 0RD4700F609 470 OHM 1/6 W 5.00%
R627 0RS2701K607 2.7K OHM 2 W 5.00% R8403 0RS0102H609 10 OHM 1/2 W 5.00%
R628 0RS2701K607 2.7K OHM 2 W 5.00% R8405 0RS0472H609 47 OHM 1/2 W 5.00%
R655 0RD4700H609 470 OHM 1/2 W 5.00% R8406 0RS0102H609 10 OHM 1/2 W 5.00%
R656 0RD4700H609 470 OHM 1/2 W 5.00% R8407 0RN5601F409 5.6K OHM 1/6 W 1.00%
R8151 0RKZVTA001D 10M OHM 1/2 W 5% R8408 0RD2201F609 2.2K OHM 1/6 W 5.00%
R8201 0RS8202K607 82K OHM 2 W 5.00% R8409 0RS5602H609 56K OHM 1/2 W 5.00%
- 24 -
For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film
the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film
digit in the P/No. means as CE : Electrolytic RN : Metal Film
follows; RF : Fusible
LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION
R8410 0RS4702H609 47K OHM 1/2 W 5.00% R8807 180-A01H RW ROUND G 2W 0.27 J
R8412 0RD1502F609 15K OHM 1/6 W 5.00% R8808 0RMZVBK002B 47K OHM 5W 5% RSR V-TYPE(PITCH
R8413 0RD3002F609 30K OHM 1/6 W 5.00% R8809 0RS3902K607 39K OHM 2 W 5.00%
R8414 0RN1002F409 10K OHM 1/6 W 1.00% R8814 0RD3301F609 3.3K OHM 1/6 W 5.00%
R8415 0RD1501F609 1.5K OHM 1/6 W 5.00% R8815 0RD4700F609 470 OHM 1/6 W 5.00%
R8416 0RD2001F609 2K OHM 1/6 W 5.00% R8816 0RS2701K607 2.7K OHM 2 W 5.00%
R8418 0RD1002F609 10K OHM 1/6 W 5.00% R8816 0RS2701K607 2.7K OHM 2 W 5.00%
R8419 0RD1002F609 10K OHM 1/6 W 5.00% R8817 0RS2701K607 2.7K OHM 2 W 5.00%
R8421 0RMZVBK001D 0.33 OHM 5W J(5%) MPR V-TYPE(P R8817 0RS2701K607 2.7K OHM 2 W 5.00%
R8423 0RN7502F409 75K OHM 1/6 W 1.00% R8818 0RS2701K607 2.7K OHM 2 W 5.00%
R8425 0RD2201F609 2.2K OHM 1/6 W 5.00% R8819 0RS2701K607 2.7K OHM 2 W 5.00%
R8501 0RS0472H609 47 OHM 1/2 W 5.00% R8820 0RD1002F609 10K OHM 1/6 W 5.00%
R8502 0RS0102H609 10 OHM 1/2 W 5.00% R8820 0RS2701K607 2.7K OHM 2 W 5.00%
R8503 0RD4700F609 470 OHM 1/6 W 5.00% R8823 0RD0912F609 91 OHM 1/6 W 5.00%
R8504 0RS0472H609 47 OHM 1/2 W 5.00% R8824 0RD1301F609 1.3K OHM 1/6 W 5.00%
R8505 0RS0102H609 10 OHM 1/2 W 5.00% R8825 0RD4701F609 4.7K OHM 1/6 W 5.00%
R8507 0RS0102H609 10 OHM 1/2 W 5.00% R8826 0RD5100F609 510 OHM 1/6 W 5.00%
R8508 0RS0472H609 47 OHM 1/2 W 5.00% R8827 0RD4701F609 4.7K OHM 1/6 W 5.00%
R8509 0RS0102H609 10 OHM 1/2 W 5.00% R8828 0RD1001F609 1K OHM 1/6 W 5.00%
R8510 0RS0472H609 47 OHM 1/2 W 5.00% R8830 0RD1002F609 10K OHM 1/6 W 5.00%
R8514 0RD1002F609 10K OHM 1/6 W 5.00% VR801 0RV5102D550 1K OHM 6 AG L3P5, 2.5 -
R8516 0RD1502F609 15K OHM 1/6 W 5.00% VR8401 180-F03L EVN-DJAA03 B104 SEMI-FIX(H)
R8517 0RD1503H609 150K OHM 1/2 W 5.00% VR8501 180-F03L EVN-DJAA03 B104 SEMI-FIX(H)
R8518 0RN1002F409 10K OHM 1/6 W 1.00%
SWITCH
R8519 0RD3301F609 3.3K OHM 1/6 W 5.00%
R8522 0RD1002F609 10K OHM 1/6 W 5.00% SW001 140-315A SWITCH,TACT SKHV17910B NON 12V
R8523 0RD1002F609 10K OHM 1/6 W 5.00% SW002 140-315A SWITCH,TACT SKHV17910B NON 12V
R8524 0RN5602F409 56K OHM 1/6 W 1.00% SW003 140-315A SWITCH,TACT SKHV17910B NON 12V
R8525 0RN6202F409 62K OHM 1/6 W 1.00% SW004 140-315A SWITCH,TACT SKHV17910B NON 12V
R8526 0RN8202F409 82K OHM 1/6 W 1.00%
FILTER
R8527 0RD8202H609 82K OHM 1/2 W 5.00%
R8528 0RD3302F609 33K OHM 1/6 W 5.00% F601 6200VJS001A FILTER,EMI ZJY51R5-4P DC 50VOLT 2A
R8529 0RN8202F409 82K OHM 1/6 W 1.00% F602 6200VJS001A FILTER,EMI ZJY51R5-4P DC 50VOLT 2A
R8530 0RD4700F609 470 OHM 1/6 W 5.00% L102 6210VC0006A FILTER,EMC FBMH3216 HM501NT
R8531 0RD4700F609 470 OHM 1/6 W 5.00% L104 6210VC0006A FILTER,EMC FBMH3216 HM501NT
R8532 0RS1001H609 1K OHM 1/2 W 5.00% L105 6210VC0006A FILTER,EMC FBMH3216 HM501NT
R8533 0RD2201F609 2.2K OHM 1/6 W 5.00% L201 6210VC0006A FILTER,EMC FBMH3216 HM501NT
R8536 0RS2202H609 22K OHM 1/2 W 5.00% L202 6210VC0006A FILTER,EMC FBMH3216 HM501NT
R8538 0RMZVBK004D 6.8 OHM 10W +/-5% RWS V-TYPE L250 6210VC0006A FILTER,EMC FBMH3216 HM501NT
R8539 0RMZVBK004D 6.8 OHM 10W +/-5% RWS V-TYPE L251 6210VC0006A FILTER,EMC FBMH3216 HM501NT
R8540 0RMZVBK004D 6.8 OHM 10W +/-5% RWS V-TYPE L252 6210VC0006A FILTER,EMC FBMH3216 HM501NT
R8541 0RS3902K607 39K OHM 2 W 5.00% L253 6210VC0006A FILTER,EMC FBMH3216 HM501NT
R8542 0RS3902K607 39K OHM 2 W 5.00% L401 6210VC0006A FILTER,EMC FBMH3216 HM501NT
R8543 0RS2202H609 22K OHM 1/2 W 5.00% L402 6210VC0006A FILTER,EMC FBMH3216 HM501NT
R8544 0RS3902K607 39K OHM 2 W 5.00% L403 6210VC0006A FILTER,EMC FBMH3216 HM501NT
R8545 0RD1503H609 150K OHM 1/2 W 5.00% L404 6210VC0006A FILTER,EMC FBMH3216 HM501NT
R8801 0RS3902K607 39K OHM 2 W 5.00% L405 6210VC0006A FILTER,EMC FBMH3216 HM501NT
R8802 0RS3902K607 39K OHM 2 W 5.00% L407 6210VC0006A FILTER,EMC FBMH3216 HM501NT
R8803 0RS0332H609 33 OHM 1/2 W 5.00% L408 6210VC0006A FILTER,EMC FBMH3216 HM501NT
R8804 0RD2701F609 2.7K OHM 1/6 W 5.00% L409 6210VC0006A FILTER,EMC FBMH3216 HM501NT
R8805 0RD4701F609 4.7K OHM 1/6 W 5.00% L411 6210VC0006A FILTER,EMC FBMH3216 HM501NT
R8806 0RD1001F609 1K OHM 1/6 W 5.00% L412 6210VC0006A FILTER,EMC FBMH3216 HM501NT
- 25 -
For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film
the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film
digit in the P/No. means as CE : Electrolytic RN : Metal Film
follows; RF : Fusible
LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION
L501 6210VC0006A FILTER,EMC FBMH3216 HM501NT ACCESSORIES
L502 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L503 6210VC0006A FILTER,EMC FBMH3216 HM501NT A1 3828VA0303A MANUAL,OWNERS NP00KB MZ-60PZ13 LG
L504 6210VC0006A FILTER,EMC FBMH3216 HM501NT A2 6710V00067M REMOTE CONTROLLER
L505 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L506 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L507 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L508 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L509 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L601 150-F09A FILTER,EMC SQE2222 7-14MH 0.37PHY 48TURN
L602 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L603 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L604 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L620 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L701 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L802 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L803 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L805 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L806 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L809 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L810 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L811 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L812 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L815 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L901 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L902 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L903 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L1101 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L1720 6210VC0006A FILTER,EMC FBMH3216 HM501NT
L8301 6200JB8006D FILTER,EMC LS614046 4600UH, 1.4
L8302 6200JB8006D FILTER,EMC LS614046 4600UH, 1.4
L8303 6200JB8006D FILTER,EMC LS614046 4600UH, 1.4
L8305 150-F06D FILTER,EMC SQE2930
L8306 6200VLB005E FILTER,EMC COOL-27(TROIDAL) ,82MH 1.4PHY
L8401 125-022K FILTER,EMC FERRITE 1UH
L8801 125-022K FILTER,EMC FERRITE 1UH
L8802 125-022K FILTER,EMC FERRITE 1UH
X201 6202VDB007B RESONATOR,CRYSTAL HC49U 20.250MHZ 3
X601 156-A02M RESONATOR,CRYSTAL HC49U 18.432MHZ 30P
X701 6202VDT002B RESONATOR,CRYSTAL SX-1SMD 14.318MHZ
MISCELLANEOUS
PA001 6726VH0001A REMOTE CONTROLLER RECEIVER,TSOP1238RF1 38KHZ
P801 6410VEH003B POWER,CORD
RL8301 6920VA1001A RELAY,FORM DH12D1-O(M)-16A
RL8302 6920VA1001A RELAY,FORM DH12D1-O(M)-16A
TY8501 6030V00001A SCR,TF541S 500V 5A
VA8301 164-003G VARISTOR,TVR621D14A 620V 10% U
VA8302 164-003G VARISTOR,TVR621D14A 620V 10% U
X1101 6204V00001K OSCILLATOR,SCO-0650-27.0M 27
- 26 -
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
